TM8500+
TM8500+ - Image 2
TM8500+ - Image 3
TM8500+ - Image 4
TM8500+ - Image 5
Categories: ,

TM8500+

*Taxes Extra

The TalkPRO TM8500+ is a professional DMR Tier II mobile radio designed for ports, logistics hubs, public transport, security teams, and mission-critical operations. Supporting voice, SMS, and GPS location tracking, it combines dual-mode communication, multisite IP connectivity, AES-256 encryption, and Bluetooth in a rugged mobile platform. With automatic roaming and a colour TFT display, the TM8500+ delivers secure and dependable communication across wide-area networks.

Highlights:

  • GIS Location Tracking
  • AES-256 Encryption
  • 14-Character TFT Colour Display
  • Automatic Roaming
  • Dual Mode (Digital / Analog)

Enquire Now
Chat on WhatsApp
Categories: ,

Rugged, Built to Last

Wide Area Coverage

Long Lasting Battery

Expert Service Care

Large Dealer Network

Product Overview

General

Technical Specifications
Frequency Range 136–174MHz / 400–470MHz
Channel Capacity 1024
Zones 64
Channel Spacing Analog: 12.5kHz / 25kHz – Digital: 12.5kHz
Dimensions 156(L) × 158(W) × 47(H) mm
Weight 1.3kg
Type of Emission Analog: 11K0F3E & 16K0F3E – Digital: 4FSK – 7K60FXD (Data) – 7K60FXE (Voice) – 7K60FXW (Voice & Data)
Power Source 13.8V DC ±15%
Encryption AES-256 Inbuilt
Digital Vocoder AMBE+2
Applicable Standard ETSI EN301 489-1, EN301 489-5
Protocol & Technology DMR Open Standard TDMA
Display 14-Character TFT Colour Display
Bluetooth Inbuilt Bluetooth
GPS GIS Tracking
Operating Mode Dual Mode (Digital / Analog)
Auto Roaming Supported
Voice Recording Optional
Channel Announcement Hindi (Optional)
User Selectable Channel for TX Supported Even on Priority Scan
Certification Indian Government Laboratory Certified
Military Standards MIL-STD 810C / 810D / 810E / 810F / 810G

Technical

Technical Specifications
RF Power Output 25W Programmable
Frequency Stability Better than ±1.5 PPM
Modulation Limiting ±2.5kHz @ 12.5kHz
Audio Distortion (Transmitter) Less than 3%
Modulation Fidelity +1, -3dB for 6dB
Spurious Emission Better than -70dB
Output Impedance 50Ω
FM Hum & Noise Better than -40dB @ 12.5kHz
Adjacent Channel Power Better than -60dB @ 12.5kHz
Frequency Spread ≥28mHz
Analog Sensitivity 0.25μV @ 12dB SINAD
Digital Sensitivity 0.25μV @ 5% BER
Adjacent Channel Sensitivity Better than 60dB
Spurious & Image Rejection Better than 65dB
Audio Output 3W @ Less than 3% BER
Audio Response +1, -3dB for 6dB/Octave Pre-emphasis
Rated Audio Distortion Less than 3%
Intermodulation Better than 70dB
GPS Precision Horizontal Accuracy ≤10m (Good Signal)
TTFF (Cold Boot) < 1 minute (with good signal)
TTFF (Hot Boot) < 10 seconds (with good signal)

Environment

Environment
Operating Temperature -30°C to +70°C
Storage Temperature -40°C to +85°C
Humidity Max 95% @ +40°C (Non-Condensing)
IP Rating IP54

Description

The TalkPRO TM8500+ is a professional DMR Tier II mobile radio designed for ports, logistics hubs, public transport, security teams, and mission-critical operations. Supporting voice, SMS, and GPS location tracking, it combines dual-mode communication, multisite IP connectivity, AES-256 encryption, and Bluetooth in a rugged mobile platform. With automatic roaming and a colour TFT display, the TM8500+ delivers secure and dependable communication across wide-area networks.

Highlights:

  • GIS Location Tracking
  • AES-256 Encryption
  • 14-Character TFT Colour Display
  • Automatic Roaming
  • Dual Mode (Digital / Analog)
